escpod bam-filter¶

Filter reads from a POD5 file based on a paired BAM file. Supports filtering by mapped status, genomic region, and mapping quality.

escpod bam-filter

Usage¶

escpod bam-filter -b <BAM> -o <OUTPUT> [OPTIONS] <INPUT>

Arguments¶

Argument	Description
`<INPUT>`	Input POD5 file or directory

Options¶

Option	Description
`-b, --bam <FILE>`	Input BAM file (required)
`-o, --output <FILE>`	Output POD5 file (required)
`--mapped`	Keep only mapped reads
`--region <REGION>`	Filter by genomic region (chr or chr:start-end)
`--quality <MAPQ>`	Minimum mapping quality
`-h, --help`	Print help

Examples¶

Extract Mapped Reads¶

Keep only reads that mapped to the reference:

escpod bam-filter -b aligned.bam -o mapped.pod5 --mapped experiment.pod5

Filter by Region¶

Extract reads mapping to a specific chromosome or region:

# All reads on chromosome 1
escpod bam-filter -b aligned.bam -o chr1.pod5 --region chr1 experiment.pod5

# Reads in a specific region
escpod bam-filter -b aligned.bam -o region.pod5 --region chr1:1000000-2000000 experiment.pod5

Filter by Mapping Quality¶

Keep only high-quality alignments:

escpod bam-filter -b aligned.bam -o high_quality.pod5 --quality 30 experiment.pod5

Combined Filters¶

Combine multiple filter criteria:

escpod bam-filter -b aligned.bam -o filtered.pod5 \
    --mapped --region chr1 --quality 20 experiment.pod5

Process a Directory¶

Filter all POD5 files in a directory:

escpod bam-filter -b aligned.bam -o filtered.pod5 pod5_directory/

BAM Index¶

Region queries require a BAM index (.bai file). If the index doesn't exist, escpod will automatically create one:

Info: BAI index not found, creating aligned.bam.bai...
Done: Created BAI index: aligned.bam.bai

Output¶

The command prints filtering statistics:

Filtering experiment.pod5 using BAM aligned.bam
Output: filtered.pod5
  Filter: mapped reads only
  Filter: region chr1
  Filter: MAPQ >= 20
Scanning BAM file...
50000 read IDs from 75000 BAM records
Scanning POD5 files for dictionary values...
45000 reads found
Filtering [████████████████████████████████████████] 45000/45000
Filtered 45000 reads from 100000 total (45.0%)
Note: 5000 BAM read IDs were not found in POD5 file(s)

Notes¶

Read IDs are matched by UUID from BAM query names
Signal data is kept compressed during copying for efficiency
Run info is preserved and deduplicated when processing multiple files
Reads not found in the BAM file are excluded from output
